TANFON Lithium Battery Advantages The process is divided into gears to ensure 100% discharge for 3500 cycles, and 80% discharge depth can be 6000 times; The data of electric core can be traced,the whole chain control and perfect aft
Place Of Origin: Foshan, Guangdong Province, China
BrandName: TANFON
MOQ: 1 set,Accpet OEM &ODM
Certificate: TUV, ETL, ISO, CE, RoHS
Payment: T/T, L/C, Paypal, Western Union
industry leading technology
uninterruptible power supply
online service
Applications :
♦Wheelchairs and scooters
♦Solar/wind energy storage
♦Back-up power for small UPS
♦Golf trolleys & buggies
♦Electric bikes
Product Specification:
Model/Parameters |
TFES96100 |
TFES96200 |
Basic |
||
Normal Voltage [V] |
102.4 |
|
Normal Capacity [Ah] |
100 |
200 |
PACK |
32S1P |
32S1P-2P |
Operating Voltage [V] |
90~112 |
|
Rated energy [kWh] |
10.24 |
20.48 |
Battery Type |
LiFePO4(LFP) |
|
Ah Efficiency [%] |
99.5 |
|
Wh Efficiency [%] |
96 |
|
Standard Power [kW] |
10.0 |
20.0 |
Recommended Charging current [A] |
<50 |
<100 |
Maximum Discharging current [A] |
100 |
100 |
Dimension & Weight |
||
Dimension(L*W*H) [mm] |
442*800*235 |
(442*800*235)*2 |
Weight [Kg] |
85 |
170 |
Communication |
||
Battery to Inverter |
RS485 |
|
Battery to Battery/BMS |
RS485 |
|
Capacity Indicator |
4LED (25%, 50%, 75%, 100%) |
|
Switch ON/OFF |
Button & MCB |
|
Environment |
||
Operating Temperature [℃] |
-10 to 55 |
|
Relative Humidity [%] |
5 to 95 |
|
Altitude [m] |
Below 4000 |
|
Standard Comply |
||
Transport Testing Requirement |
|
|
Cycle Life [80% DOD, @0.5C, 25℃] |
> 6000 Cycles |
|
Warranty [Year] |
3 years |
Lithium battery case:
certification:
