5500watt with or Without Battery 5.5kw 48V 110A MPPT off-Grid Home Solar System
Place Of Origin: Foshan, Guangdong Province, China
BrandName: Tanfon Solar
MOQ: 1 set,Accpet OEM &ODM
Certificate: TUV, ETL, ISO, CE, RoHS
Payment: T/T, L/C, Paypal, Western Union
industry leading technology
uninterruptible power supply
5500watt with or Without Battery 5.5kw 48V 110A MPPT off-Grid Home Solar System Hybrid Power
Tanfon factory supply: off grid solar system, on grid solar system, on and off grid hybrid solar system, off grid solar system without battery.
Off grid inverter work without battery Technical advantages:
Off grid solar system without battery design bebnefits
TANFON off grid system SPII-2kw(running without battery)
Solar panel rated output power: 2000W
Suitable for daily power consumption : >12KWH
FS250W mono solar panel(poly optional)
Vmp: 30V Voc: 36V Imp 8.67A
Size : 1640*992*40mm
25 years life time (CE RoHS)
Coated steel Glass: 3.2mm Tempered
Terminal block: IP65 with MC4 connector
Efficiency performance: 25 years 80%, 20 year 85%, 10 years 90%
Connect: 4pcs connect to PV combiner
Power capacity: TF-smart-2000-24
MPPT voltage: 120V-450V
Maximum PV Array Open Circuit Voltage: 500V
Allowed Voltage Range Of Grid: 220V
Communication interface: WIFI
Warranty: 2 years
Inverter size: 100 x 300 x 440mm
Working without battery.
Slope Rooftop or Flat rooftop
including complete fittings
wind load: 55m/s, snow load: 1.5kn/m2
structure: Anodized Aluminum + stainless steel, Angle adjustable
(other type of rack can be customized as per client's requirement )
4mm2 cable, (one red and one black)
International standard, with specification suitable for solar system
Off grid solar power system working without battery
3.2kw/5kw full capacity output 220V, 230V, 240V(optional)
PV input 120VDC-500VDC
Solar and grid work together at the same time, for example: your power consumption is 5KW/H, you get 4000W/H from PV, inverter will get grid 1000W/H to take load (save electricity bill)
Off grid solar power system inverter working without battery design
We provide complete set solar power system that include all parts for customers, installation tool can be choose. Customers can easy install the system according to our detailed connect diagram and user’s manual.
Off Grid Solar Power System project update
Why Choose Tanfon?
Tanfon off grid solar power system certificates
Off grid solar power system Shipping
Material in stock can be produced (procedure 5-20days) right away after pre-payment confirmation. COSCO Mearsk MSC ship to worldwide for safe shipping, don't worry about package damage or loss. It takes about 15-40 days to worldwide, Please note us your contact details include your phone number for easy contacting from shipping company officer.
|Off grid solar power system FAQ|
Q: What can be included for this system from TANFON?
A:This system includes: Solar panels, PV array combiner, Off grid Solar inverter, Solar panel mounting rack, PV cables.
Q: Is the solution for complete set? If not, what else are needed?
A: Yes, we can provide solution of complete set. If you don't need complete set, basic parts are available also.
Q: Is the system solution always the same? Can I customize one?
A: No. We have professional teams making solutions for our clients. Solutions are mainly customized based on different sunshine time and power consumption.
Q: Who arranges the shipping?
A: We could help you arrange the shipment, we have good service forwarder in Guangzhou.
Q: What is the lifetime of the solar power system?
A: Solar panel’s lifetime are 25 years, charger controllers 5~ 7 years, inverters can be about 20 years
Q:what is TANFON solar system after sales service?
A: during the warranty ,Solar panel--ship free new one ;battery—ship the new one, Inverter / controller--ship free PCB by DHL or Fedex.
We accept OEM and small trial orders, contacting with us now for more information. All inquiries will be replied with in 24 hours.
